Shenzhen Jinzhi Optoelectronics Technology Co., Ltd. has been deeply involved in the field of optical fiber communications for many years, focusing on the research and development, production and service of optical fiber solutions, with independent intellectual property technology and a nationwide service network. More importantly, Shenzhen Jinzhi Optoelectronics Technology Co., Ltd. takes "high speed, stability and security" as its concept, and provides full-scenario optical fiber communication solutions for home, enterprise, industry and other scenarios, helping to upgrade information transmission in the digital age.
M.O.S.T. (Media Oriented SystemsTransport multimedia guidance system transmission) is a local area network that connects audio equipment, car TV, global system and car phone equipment to each other. It occupies a dominant position in the field of short-distance data transmission and industrial automation, especially in terms of improving car safety performance and information function. Development and application of plastic optical fiber connection technology; in conjunction with the application of plastic optical fiber in automobiles, a series of M.O.S.T. plastic optical fiber patch cords were launched to ensure high quality standards of M.O.S.T. plastic optical fiber patch cords with strict end surface polishing technology and rigorous optical fiber testing methods.
Features:
Light weight, save car wiring space
Data is not affected by electromagnetic interference
High-speed data transmission, large data volume, MOST25 standard
Data rate is 25Mbps, MOST150 standard data
150Mbps
Can transmit synchronous data, asynchronous data and control data
Support Plug and Play (Plugand Play) mechanism
Multimedia devices connected
Scope of application:
Digital broadcasting
Video display
Interactive Security System
GPS navigation system
product features:
It adopts independent MOST plastic optical fiber connector developed and produced by itself, with bayonet design, compact structure, tensile, waterproof, high temperature design, low insertion loss, high precision coupling, which can ensure data transmission. The exterior is made of PE, PVC and other materials, which are anti-wear, anti-corrosion, anti-gravity, high and low temperature non-conductive, and no electromagnetic interference radiation. It is designed and developed for automotive multimedia systems. The assembly process exceeds industry standards. Widely used in cars
Performance specifications:
Core material diameter: Φ1.0
Core material: imported Japanese optical fiber
Finished product diameter: Φ2.3
Outer cover material: CPE, PE, PVC
Cover color: orange, other colors can be customized
Attenuation: less than 180dB/km
Working temperature: -55℃-+85℃
Standard length: 1000mm, any size can be customized 0-100m
Compliance with standards: European ROHS certification, CE certification
Fiber parameters:
