AVAGO application

1. Application of industrial optical fiber products in wind turbines and wind farms

Jinzhi provides highly reliable industrial fiber optic components for isolation in the data acquisition/control and power generation markets. These products have excellent high insulation voltage performance and immunity to EMI, and can be installed and operated near power transmission pipelines that can produce destructive electrical interference. As the global demand for renewable energy grows, the design of wind turbines has become larger and larger. Jinzhi's industrial fiber optic products provide a wide range of data rates and link lengths for many applications in this power generation market.


394b55697f0959022c45fee31509f17微信图片_20241212154005imagee4d08ff2ca0f8d3f1582b89ac71f155image

2. The application of optical fiber in solar energy

In a solar farm power generation system, solar heat generates a lot of current. In order to protect equipment from huge current leakage, electrical insulation is essential to ensure the quality and reliability of the power system. Optical fiber can provide insulation protection to prevent high voltage or current interference.

The key applications of fiber optic components in solar systems include:

1 Power electronic gate driver for inverter

2 Solar tracking control and communication board

3 Substation automation and protection relays for solar power plants


solar energy generation


Figure 1 Solar power generation frame Solar panels collect solar energy and convert it into electrical energy through photovoltaic modules or solar collectors. In order to integrate the electricity generated by the solar panels into the transmission line, the electricity needs to be converted into utility-grade alternating current

Examples of power semiconductor devices available on the market:

1 Insulated gate bipolar transistor (IGBT)                   2 Delete level power-off thyristor (GTO)        3 Integrated Gate Commutation Thyristor (IGCT)

4 Symmetric Gate Commutation Thyristor (SGCT)   5 Launcher turn-off thyristor (ETO)


Fiber optic tissue is usually used to control high voltage and current switches and current switching devices, and has reliable control and feedback signals (Figure 2, Table 1)



微信图片_20241212160015

微信图片_20241212160143微信图片_20241212160235


50e76dd164ae119b39f97eefe4c8c67
