Asahi Kasei's Multi-core POF MCL-1500-1.75, MCL-1500-22, and MCL-2000-24 are high-performance multi-core plastic optical fibers. The MCL-1500-1.75 is an imaging fiber with a 1.5mm core diameter and 13,000 pixels, suitable for medical endoscopes; the MCL-1500-22 is an optical fiber with a 2.2mm jacket suitable for industrial applications; and the MCL-2000-24 is an endoscope fiber with a 2.0mm core diameter for precision imaging. These fibers, with their high pixel count, transmit clear images, assisting in disease diagnosis in medicine and equipment testing in industry. With Asahi Kasei's quality assurance, they provide reliable image transmission solutions for both the medical and industrial sectors.
model：POF MCL-1500-1.75, MCL-1500-22, MCL-2000-24
Asahi Kasei Multicore POF: MCL-1500-1.75 Imaging Fiber, MCL-1500-22 Optical Fiber, MCL-2000-24 Endoscopy Fiber
1. Name: Multicore Plastic Imaging Fiber
2. Models: MCL-1500-1.75, MCL-1500-22, MCL-2000-24
3. Brand: Asahi Kasei
4. Product Specifications
MCL-1500-1.75: This 1300nm wavelength image transmission fiber features a 1.5mm clear core diameter and a 1.75mm polyethylene jacket. Its core material is PMMA, with cladding made of fluorinated polymer, a numerical aperture of 0.5, and it consists of 13,000 fibers. The operating temperature range is -55°C to 60°C, enabling stable 1300nm wavelength image transmission even in extreme temperature conditions.
This characteristic makes it highly suitable for a variety of professional fields that demand precise image transmission at the 1300nm wavelength. For instance, in industrial non-destructive testing, it can efficiently transmit clear images through narrow and harsh environments, helping inspectors accurately detect internal flaws of workpieces. In medical imaging, it plays a crucial role in some specialized endoscopic procedures, ensuring high-quality image transmission to assist doctors in making accurate diagnoses. Moreover, its 13,000 fibers contribute to excellent image resolution, ensuring that even fine details in the transmitted images are clearly presented.
MCL-1500-22: 1.5mm clear core diameter, 2.2mm outer jacket. Using a PMMA core, it offers the same excellent optical performance and adapts to complex working environments. Its operating temperature is the same as the MCL-1500-1.75.
MCL-2000-24: 2.0mm clear core diameter, with accessories or outer jackets compatible with 2.4mm diameter. 13,000 pixels ensure high-resolution imaging and stable operation within a temperature range of -55°C to 60°C.
5. Compatible Models: Compatible with leading medical endoscope brands such as Olympus and Fujinon. For industrial inspection equipment, it is compatible with common fiberscopes for pipeline inspection.
6. Features
High-resolution imaging: 13,000 pixels provide clear images, whether observing fine structures in medical settings or identifying tiny defects within equipment during industrial inspection. Suitable Size Design: Available in various core diameters and jacket sizes, such as 1.5mm and 2.0mm core diameters and 1.75mm and 2.2mm jacket sizes, these optical fibers are suitable for use with slim endoscopes used in minimally invasive medical surgeries, as well as industrial pipe inspections of varying diameters.
7. Applications
Medical Applications: Used in medical endoscopic examinations, doctors can accurately diagnose lesions in patients through the clear images transmitted by optical fiber, assisting in the precise diagnosis and development of treatment plans.
Industrial Applications: As an industrial inspection fiber, it can penetrate deep into difficult-to-observe areas such as pipelines and machinery to detect cracks, wear, and other issues, ensuring safe production and the proper functioning of equipment.
