As a standard interface in the fields of industry and scientific research, the SMA 905 fiber optic connector is mainly used for the transmission of optical signals and the interconnection of equipment. It is widely used in laser processing, medical instruments, military communications, spectral analysis, fiber optic sensing and other scenarios, and is especially suitable for systems that require high-power transmission or anti-interference capabilities.
Regular size 250um 405um 610um SMA905 fiber optic connector, other sizes can be customized
High-Performance POF Fiber Connectors for Demanding Applications
Our SMA905/SMA906 fiber connectors provide ultra-low loss connectivity for plastic optical fiber (POF) systems across 250μm, 405μm, and 610μm core sizes. Featuring precision-machined zirconia ferrules and stainless steel housings, these industrial-grade connectors deliver:
1. <0.5dB Insertion Loss for maximum signal integrity
2. Interchangeable SMA905/SMA906 Compatibility for system flexibility
3. IP67-Rated Versions available for harsh environments
SMA905_250um
SMA905_500um
SMA905_610um
Technical Parameters Table
| Specification | Details |
| Core Sizes | 250μm, 405μm, 610μm |
| Wavelength Range | 400-850nm (Visible to NIR) |
| Connector Types | SMA905 (Male), SMA906 (Female) |
| Insertion Loss | <0.5dB @ 650nm |
| Operating Temperature | -40°C to +85°C |
| Housing Material | Stainless Steel (Corrosion-Resistant) |
| Ferrule Material | Zirconia Ceramic (High-Temperature) |
Product Specification
Application Scenario Module
1. Automotive Lighting Systems
Ideal for POF-based CAN bus networks in vehicles
Vibration-resistant design meets ISO 6722 standards
2. Industrial Sensor Networks
Reliable connectivity for factory automation POF sensors
Optional EMI-shielded versions for high-noise environments
3. Consumer Electronics
Low-cost solution for home audio optical links
610μm version optimized for red LED systems (650nm)
