Our V - pin interface fiber connector, paired with AFBR - S10PS010Z and AFBR - S10PS011Z, is crucial for Arc Flash Event Detection light detection. The AFBR - S10PS010Z has self - supervision, captures light via its translucent head, and has a wide acceptance cone. Get its datasheet, price, or find equivalents. Our Aoago Connector ensures reliable connection, making it a top choice for arc flash protection setups.
Product type: HFBR4501-4511, HFBR4503-4513, HFBR4506-4516, HFBR4531-4533, 4532, 4505, 4515
Name: V-pin Interface Fiber Optic Connector and Compatible Optical Sensor
Model: This connector is compatible with the AFBR-S10PS010Z and AFBR-S10PS011Z optical sensors. The AFBR-S10PS010Z is a self-monitoring optical sensor, while the AFBR-S10PS011Z is a miniature connector for connecting duplex plastic optical fiber cables to point sensors.
Product Specifications:
1. V-pin Interface Fiber Optic Connector: Typically compatible with 200/230µm polymer-clad optical fiber (POF), with versions also available for 1mm diameter plastic optical fiber. Some connectors utilize a simple crimp and cleave termination process, eliminating the need for epoxy, curing ovens, or time-consuming polishing.
2. AFBR-S10PS010Z Optical Sensor: Captures light and feeds it into a 1.0/2.2mm diameter duplex plastic optical fiber (POF). This light is captured through the translucent tip of the point sensor, and built-in coupling between the two optical fibers enables self-monitoring. It has a UL 94 HB flammability rating and excellent chemical resistance. Its acceptance cone exceeds 180° with high uniformity, and it offers a typical insertion loss of 13 dB. Its operating temperature range is -40°C to +85°C.
3. AFBR-S10PS011Z Micro Connector: Designed for connecting duplex POF cables to point sensors, creating a complete optical detection system link.
Compatible Models: V-pin interface fiber optic connectors are fully compatible with Avago's Versatile Link series of transmitters and receivers. Specific V-pin connector models are designed for use with AFBR-S10PS010Z and AFBR-S10PS011Z optical sensors. When building a system, ensure accurate matching according to the product instructions.
Features:
Easy Installation: The V-pin connector features a simple snap-on or snap-off design, allowing for quick installation without the need for crimping tools, significantly reducing installation time. Self-Monitoring Function: The AFBR-S10PS010Z optical sensor features a self-monitoring function that monitors the optical link status in real time, ensuring system stability.
High-Quality Materials: The connector and sensor components are made of chemically resistant materials that comply with relevant safety standards.
Purpose:
1. Arc Flash Event Detection: In scenarios such as industrial power monitoring, a system built using the AFBR-S10PS010Z optical sensor and a V-pin optical connector can accurately detect arc flash events. When abnormally strong light is detected, a timely alarm is issued, providing critical information for electrical equipment maintenance and personnel safety.
2. Light Detection: Suitable for various scenarios requiring precise light detection, such as ambient light monitoring and optical signal feedback detection in industrial automation production. Optical signals are transmitted via optical fiber, and then accurately captured and analyzed by the optical sensor to monitor light intensity and presence.
